Shapr3D and 3Dconnexion

Make your design flow

Shapr3D CAD software is on a mission to revolutionize concept design. Its mobile-first system is built to help users design where and when they want. Sketch during the commute, refine in the office, iterate in the workshop or with clients.

The Shapr3D integration with 3Dconnexion supports everyone—from CAD professionals to weekend hobbyists—with their modelling and design breakthroughs. Going from sketching to manufacture, is easy, fast and flexible with this winning product combination.

SpaceMouse

Interact naturally with designs

Specifically designed to make navigating in a 3D space easier and more intuitive, the SpaceMouse allows you to understand your model more deeply. It’s an essential—and fun—tool for anyone serious about 3D design.

  • Navigate with the SpaceMouse and free up your mouse cursor for other actions
  • Quickly enable Horizon Lock and change navigation directly in Shapr3D
  • QuickView and CustomView buttons speed up the design process

Discover the SpaceMouse product line

Play video

CadMouse

Design with comfort

When used together, Shapr3D and CadMouse give you the precision and comfort required for speedy output. A superior ergonomic design allows for sustained use for as long as you want.

  • Dedicated Middle Mouse Button to pan and rotate effortlessly
  • QuickZoom buttons for one-click zooming and centering of design details
  • Easy access to Shapr3D commands with the radial menu
  • Go compact and wireless to boost Shapr3D’s mobile design solution

Discover the CadMouse product line

Play video

Keyboard and Numpad

Tailor your workflow

Just as Shapr3D enables you to design with peak efficiency, so does the 3Dconnexion Keyboard Pro with Numpad. Fully customize the programmable keys for your software or simply use the pre-mapped profiles.

  • Complement your devices with extra programmable keys for Shapr3D
  • Advanced wrist support and key design for superior ergonomics
  • Wireless, programmable Numpad that can be stored away, freeing up desk space

Discover the Keyboard Pro with Numpad

Discover more

Play video
Video

SpaceMouse® meets Shapr3D | Webinar

Shapr3D

I’ve been using the SpaceMouse as part of my design toolbox for six years, purely because it just makes navigating CAD data more exciting and dynamic. I’m able to very easily navigate the controls to see precisely what I’m trying to understand. The SpaceMouse also makes navigating more accurate. If there’s a specific feature that I need to see from a perspective or want to rotate around to show my design team, it’s a lot easier just to use the SpaceMouse to navigate around my workflow and to show the perspectives that I need to communicate to my team.

One of the things that makes Shapr3D so effective to use on tablets is the ability to navigate in 3D along multiple dimensions at once with simple touch gestures, while simultaneously performing modeling actions with a pen. 3Dconnexion devices bring the same efficient two-handed workflow to desktops: the SpaceMouse enables quick view navigation along six degrees of freedom while the CADmouse and the keyboard can be used for precise selection and quick access to modeling actions via the command bindings.

Which features are available?

Tested Shapr3D version:
5.590
Tested 3DxWare version:
10.8.20 (Windows), 10.8.4 (macOS)
Supported platforms:
Windows, macOS

SpaceMouse

Shapr3D Navigation

  • Object Mode1
  • Target Camera Mode1
  • 2D Mode
  • Auto Rotation Center
  • Horizon Lock1
  • Rotation Lock
Learn more

Shapr3D Views

  • Fit View
  • Standard Views2
  • Custom Views
Learn more

Shapr3D Tools

  • Application commands
  • Radial Menus
  • Macros
Learn more

CadMouse

Shapr3D Navigation

  • QuickZoom
Learn more

Shapr3D Views

  • Fit View
  • Standard Views2
  • Custom Views
Learn more

Shapr3D Tools

  • Application commands
  • Radial Menus
  • Macros
Learn more

Keyboard and Numpad3

Shapr3D Tools

  • Application commands
  • Radial Menus
  • Macros
Learn more
  • 1The feature can be enabled only within the application, and not through 3Dconnexion settings
  • 2Not available on macOS
  • 3Not supported by macOS
